LV3000P Fixed Barcode Scanner for Manufacturing
Product Description
Upgrade your assembly line with the RAKINDA LV3000P—a high-performance fixed barcode scanner built for tough industrial applications. Perfect for electronics manufacturing, automotive parts, and photovoltaic production, it decodes dirty, low-contrast, or distorted barcodes with unmatched precision using advanced RAKINDA decoding tech. Its IP65-rated metal body withstands dust, water jets, and 1.5m drops, while the 46°×29° wide-angle lens ensures flexible installation. Why choose LV3000P?
– Reads ALL Codes: Supports 30+ symbologies (UPC, EAN, Code 128, QR, Data Matrix, etc.).
– Fast & Accurate: Scans 1D (>4 mil) and 2D (>9 mil) codes in milliseconds.
– Plug-and-Play: USB/RS-232 connectivity, beep/LED indicators.
– Extreme Environment Ready: Operates in -20°C to 50°C, 5–95% humidity.
Ideal for automated factories, logistics, and quality control. Boost efficiency with RAKINDA’s trusted industrial solution!
Automated Production Scanner Parameters
| Scan Performance | ||
| Resolution | 1280*800 | |
| Field of view | Horizontal 46°(H)·Vertical 29°(V) | |
|
Symbologies |
2D
1D |
Data Matrix , QR Code , Micro QR ，PDF417, Micro PDF417 MaxiCode ，Aztec, UPC A , UPC E , EAN 8 , EAN 13 , Code 128 , Code 39 , Code 93 , Code 32 , Code11 , Codabar ,Plessey , MSI , Interleaved 2 of 5 |
| Llighting | White light source | |
| Reading mode | Key mode, serial command trigger mode | |
| Reading accuracy | 1D : ≥4 mil ; 2D : ≥9 mil | |
|
Typical reading depth of field |
Code39(4mil) 60mm~200mm | |
| Code39(5mil) 60mm~250mm | ||
| EAN 13(13mil) 50mm~320mm | ||
| QR Code (7mil) 60mm~100mm | ||
| Data Matrix(10mil) 60mm~200mm | ||
| Print contrast | ≥20% | |
|
Mechanical and electrical parameters |
||
| Outer dimensions | 36(W) × 43 (D) × 24(H)(mm) | |
| Weight | About 100g (including 2 meters of cable) | |
| Communication interface | USB ，RS-232 ，Virtual COM Port | |
| Prompting mode | Beep, LED indicator | |
| Working voltage | DC 5V±5% | |
| Working current | 300 mA ±5% (typical), 500 mA ±5% (maximum) | |
| Wait for the electromotive force | 100 mA ±5% | |
| Enviromental Parameter | ||
| Working temperature | -20℃~+50℃ | |
| Storage temperature | -40℃~+70℃ | |
| Relative humidity | 5%~95% (no condensation) | |
| Electrostatic protection | ± 12kV (air discharge), ± 8kV (direct discharge) | |
| Drop height | 1.5 meters | |
| Levels of protection | IP65 | |
| International Certification | ||
| Levels of protection | FCC Part15 Class B ，CE ，EMC Class B | |
